General Specifications

Analog audio input

8 x RCA (Single Ended)

Stereo analog global output (global input looped to global output)

2 x RCA (Single Ended)

Speaker output

Phoenix block connectors, accommodates up to 12AWG wire

12V trigger control

1 x 3.5mm (in), 1 x 3.5mm (out)

Power

Standard IEC

Global input select

4 x 2-position dip switches

Bridge/Mono select

4 x 2-position dip switches

Power Mode select

1 x 3-position switch – always on, 12V, auto sense

FTC Rated Output Power (20Hz– 20kHz, 2 channels driven, 1% THD max, 8Ω)

50W

Rated Power (1kHz, 20ms burst, 2 channels driven, 0.5% THD max, 8Ω)

50W

Rated Power (1kHz, 20ms burst, 2 channels driven, 0.5% THD max, 4Ω)

110W

Rated Power (8Ω Bridged, one zone driven)

185W

Frequency Response

20Hz-20kHz +/-0.5dB, at 1/8th power, all loads

THD+N (max), at rated power, 20-20kHz

<0.1%

Signal to noise ratio (min), A-weight, 20-20kHz, 8Ω mode

>100dB

Crosstalk between any zones, at 1/8th power

-80dB

Minimum output impedance

2.7Ω

Analog input impedance

20kΩ

Signal sense, wake up level

1.75 mVrms

Max undistorted analog input signal

4.6 Vrms

Fan noise, maximum, 1/8 power

50dBA SPL @ 1 meter

Power supply

Universal Mains 100–240VAC 50-60Hz

Standby power consumption

Less than 0.5W

Dimensions (H x W x D)

1.7” x 17.2” x 12.7” (43.7mm x 436.0mm x 323.0mm)

Dimensions inc. feet (H x W x D)

1.75” x 17.2” x 12.7” (44.5mm x 436.0mm x 323.0mm)

Net Weight

4.5kg
